| Nama Wahi | LMS700KF07 |
| Waitohu | Samsung |
| Rahi | 7.0 |
| Taupānga | MP4 |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 280 |
| CR | 400:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SAMSUNG |
| panel model | LMS700KF07 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 800×480(RGB) , WVGA |
| display mode | TN, Normally White, TMR |
| active area | 152.4×91.44 mm |
| outline | 163.2×104×4.7 mm |
| surface | Hard coating (3H) |
| brightness | 280 cd/m² (Typ.) |
| contrast ratio | 400 : 1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193151% |
| response time | 22 (Typ.)(Tr+Td) |
| viewing angle | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 8S3PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| input voltage | 3.3V (Typ.)(VCC) |
| application | MP4 |
| CLAA069JA11CW | CPT | 7.0 | 480×234 |
| LMS700JF01-001 | Samsung | 7.0 | 1024×600 |
| LMS700JF04-0 | Samsung | 7.0 | 1024×600 |
| LMS700KF01-001 | Samsung | 7.0 | 800×480 |
| LMS700KF05 | Samsung | 7.0 | 800×480 |
| LMS700KF06 | Samsung | 7.0 | 800×480 |
| LMS700KF07 | Samsung | 7.0 | 800×480 |
| LMS700KF15 | Samsung | 7.0 | 800×480 |
| LMS700KF21 | Samsung | 7.0 | 800×480 |
| LMS700KF23 | Samsung | 7.0 | 800×480 |
| AT070TN83 V.1 | Innolux | 7.0 | 800×480 |
| BA070WS1-200 | BOE | 7.0 | 1024×600 |
| CLAA070LB01CW | CPT | 7.0 | 800×480 |
| CLAA070NC0BCT | CPT | 7.0 | 1024×600 |
| CLAA070ND26CW | CPT | 7.0 | 1024×600 |
| DLC0700EZG-T-2 | Other | 7.0 | 800×480 |
| HSD089IFW1-A00 | HannStar | 8.9 | 1024×600 |
| LMS700KF01-001 | Samsung | 7.0 | 800×480 |
| N070LGE-L21 | Innolux | 7.0 | 1024×600 |
| TM070DDH09 | Tianma | 7.0 | 1024×600 |
