LM170E03-TLH1

LM170E03-TLH1
LM170E03-TLH1
LM170E03-TLH1 thumb LM170E03-TLH1 thumb
Waitohu
LG Display
Rahi
17.0
Taupānga
DMPC
Whakatau
1280×1024
Te tito
LCM
Tirohanga
250
CR
800:1
Nga Tae
16.7M
Whakamuri
CCFL
Atanga
LVDS
In Stock
1410
Whakatakotoranga

Nama Wahi LM170E03-TLH1
WaitohuLG Display
Rahi17.0
TaupāngaDMPC
Whakatau1280×1024
Te titoLCM
Tirohanga250
CR800:1
Nga Tae16.7M
WhakamuriCCFL
AtangaLVDS
panel brandLG Display
panel modelLM170E03-TLH1 3 Compatible model
panel type a-Si TFT-LCD , LCM
panel size17.0 inch
resolution1280(RGB)×1024 , SXGA
display modeTN, Normally White, Transmissive
active area337.92×270.336 mm
outline358.5×296.5×16.5 mm
surfaceAntiglare, Hard coating (3H)
brightness250 cd/m² (Typ.)
contrast ratio800:1 (Typ.)
display colors16.7M (6-bit + Hi-FRC)
response time1.2/3.8 (Typ.)(Tr/Td)
viewing angle85/85/75/85 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type2 pcsCCFLWithout Driver
signal interfaceLVDS (2 ch, 8-bit), 30 pins
input voltage5.0V (Typ.)
applicationDMPC
