| Nama Wahi | LM170E01-A4 |
| Waitohu | LG Display |
| Rahi | 17.0 |
| Taupānga | DMPC |
| Whakatau | 1280×1024 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 450:1 |
| Nga Tae | 16.2M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | LG.Philips LCD |
| panel model | LM170E01-A4 10 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1280(RGB)×1024 , SXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 337.92×270.336 mm |
| outline | 358.5×296.5×17.5 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 450:1 (Typ.) |
| display colors | 16.2M (6-bit + FRC), CIE193172% |
| response time | 2/14 (Typ.)(Tr/Td) |
| viewing angle | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
| LM170E01-A4 | LG Display | 17.0 | 1280×1024 |
| LM170E01-TLB3 | LG Display | 17.0 | 1280×1024 |
| LM170E01-TLBF | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLB1 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ1 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ2 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ5 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ6 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLL1 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLL2 | LG Display | 17.0 | 1280×1024 |
| HT215F01-100 | BOE | 21.5 | 1920×1080 |
| LM190E08-TLG2 | LG Display | 19.0 | 1280×1024 |
| LM215WF4-TLE7 | LG Display | 21.5 | 1920×1080 |
| LM230WF5-TLD1 | LG Display | 23.0 | 1920×1080 |
| LM240WU8-SLA3 | LG Display | 24.0 | 1920×1200 |
| LTM230HP07 | Samsung | 23.0 | 1920×1080 |
| M185BGE-P02 | Innolux | 18.5 | 1366×768 |
| M236H3-L05 | Innolux | 23.6 | 1920×1080 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| P190MWW1-404 | IVO | 19.0 | 1440×900 |
