| Nama Wahi | HX104X01-212 |
| Waitohu | HYDIS |
| Rahi | 10.4 |
| Taupānga | PAD |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 340 |
| CR | 600:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | HYDIS |
| panel model | HX104X01-212 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.4 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | AFFS+, Normally Black, Transmissive |
| active area | 210.4×157.8 mm |
| outline | 238.6×173.2×6.8 mm |
| surface | Antiglare |
| brightness | 340 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 262K (6-bit), CIE193140% |
| response time | 36 (Typ.)(Tr+Td) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 7S6PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
