| Nama Wahi | HV121WX5-111 |
| Waitohu | HYDIS |
| Rahi | 12.1 |
| Taupānga | PAD |
| Whakatau | 1280×800 |
| Te tito | LCM |
| Tirohanga | 220 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | BOE HYDIS |
| panel model | HV121WX5-111 3 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 1280(RGB)×800 , WXGA |
| display mode | AFFS, Normally Black, Transmissive |
| active area | 261.12×163.2 mm |
| outline | 276.8×180×6.8 mm |
| surface | Antireflection |
| brightness | 220 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 12S4PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
| HV121WX4-110 | HYDIS | 12.1 | 1280×800 |
| HV121WX4-120 | HYDIS | 12.1 | 1280×800 |
| HV121WX5-110 | HYDIS | 12.1 | 1280×800 |
| HV121WX5-111 | HYDIS | 12.1 | 1280×800 |
| HV121WX5-113 | HYDIS | 12.1 | 1280×800 |
| HV121WX5-114 | HYDIS | 12.1 | 1280×800 |
| HV121WX5-120 | HYDIS | 12.1 | 1280×800 |
| HV121WX5-121 | HYDIS | 12.1 | 1280×800 |
| HV121WX6-111 | HYDIS | 12.1 | 1280×800 |
| HV121WX6-112 | HYDIS | 12.1 | 1280×800 |
| B101UAN01.7 HW1A | AUO | 10.1 | 1920×1200 |
| BP070WS1-102 | BOE | 7.0 | 1024×600 |
| HE070IA-04M | Innolux | 7.0 | 800×1280 |
| HJ070IA-04K | Innolux | 7.0 | 800×1280 |
| LD070WX3-SL01 | LG Display | 7.0 | 800×1280 |
| LD070WX5-SM01 | LG Display | 7.0 | 900×1440 |
| LP097QX1-SPC3 | LG Display | 9.7 | 2048×1536 |
| LP101WX1-SLN2 | LG Display | 10.1 | 1280×800 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
| TPF0702001N | JDI | 7.0 | 1200×1920 |
