| Nama Wahi | HSD170MGW1-B01 |
| Waitohu | HannStar |
| Rahi | 17.0 |
| Taupānga | DMPC |
| Whakatau | 1440×900 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 600:1 |
| Nga Tae | 16.2M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | HannStar |
| panel model | HSD170MGW1-B01 1 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1440(RGB)×900 , WXGA+ |
| display mode | TN, Normally White, Transmissive |
| active area | 367.2×229.5 mm |
| outline | 389.2×254.5×11.8 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 16.2M (6-bit + FRC), CIE193163% |
| response time | 3/5 (Typ.)(Tr/Td) |
| viewing angle | 80/80/65/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
