| Nama Wahi | HSD123JPW1-A20 |
| Waitohu | HannStar |
| Rahi | 12.3 |
| Taupānga | Outdoor High Brightn |
| Whakatau | 1920×720 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 11S4P |
| Atanga | LVDS |
| panel brand | HannStar |
| panel model | HSD123JPW1-A20 |
| panel size | 12.3" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1920(RGB)×720, 167PPI |
| pixel format | RGB Vertical Stripe |
| display area | 292.032(W)×109.512(H) mm |
| bezel opening | 294.8(W)×112.1(H) mm |
| outline size | 308.1(W)×130(H) ×16.6(D) mm |
| surface | Antiglare |
| brightness | 850 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| display mode | IPS Pro, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 18/17 (Typ.)(Tr/Td) |
| display colors | 16.7M 70% NTSC |
| lamp type | 11S4P WLED , 30K hours , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 520g (Typ.) |
| application | Outdoor High Brightness Automotive Display |
| signal interface | LVDS (2 ch, 8-bit) , 50 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
