| Nama Wahi | H220VA01 |
| Waitohu | AUO |
| Rahi | 2.2 |
| Taupānga | Mobile Phone |
| Whakatau | 240×320 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 75:19:1 |
| Nga Tae | 262K |
| Whakamuri | 4S1P |
| Atanga | Parallel |
| manufacturer | AUO |
| screen size | 2.2 inch |
| pixel number | 240(RGB)×320 (QVGA) 180PPI |
| active area(mm) | 33.84 × 45.12 (H×V) |
| bezel area(mm) | 35.4 × 46.92 (H×V) |
| luminance | 100 cd/m² (Typ.) |
| viewing angle | 47/28/30/80 (Typ.)(CR≥10) |
| good view at | 6 o'clock |
| color depth | 262K 42% NTSC |
| mass | - |
| refresh rate | - |
| signal type | Parallel RGB (1 ch, 6-bit) + SPI , 39 pins FPC |
| voltage supply | 2.8V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| model name | H220VA01 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 40.6 × 56.66 × 3.11 (H×V×D) |
| treatment | - |
| contrast ratio | 75 : 1 (Typ.) (TM) 9:1 (Typ.) (RF) |
| response | 29 (Typ.)(Tr+Td) ms |
| work mode | TN, Normally White, Transflective |
| backlight | 4S1P WLED , No Driver |
| used for | Mobile Phone |
| touchscreen | Without |
