| Nama Wahi | EE070NA-01D |
| Waitohu | Innolux |
| Rahi | 7.0 |
| Taupānga | MP4 |
| Whakatau | 1024×600 |
| Te tito | CELL |
| Tirohanga | 0 |
| CR | 700:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | No B/L |
| Atanga | LVDS |
| panel brand | CHIMEI INNOLUX |
| panel model | EE070NA-01D |
| panel type | a-Si TFT-LCD , CELL |
| panel size | 7.0 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 153.6×90 mm |
| outline | 160×101.1×1.43 mm |
| surface | Glare (Haze 0%), Hard coating |
| glass depth | 0.50+0.50 mm |
| transmissivity | 3.5% (Typ.)(with Polarizer) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 75/75/70/75 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| signal interface | LVDS (1 ch, 6/8-bit), 40 pins |
| input voltage | 3.3/11/20/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| application | MP4 |
