| Nama Wahi | CM546B2-001 |
| Waitohu | CSOT |
| Rahi | 5.5 |
| Taupānga | Mobile Phone |
| Whakatau | 1080×1920 |
| Te tito | LTPS TFT-LCD, CELL |
| Tirohanga | |
| CR | 1500:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | |
| panel brand | CSOT |
| panel model | CM546B2-001 |
| panel size | 5.5" |
| panel type | LTPS TFT-LCD, CELL |
| resolution | 1080(RGB)×1920, FHD, 403PPI |
| pixel format | RGB Vertical Stripe |
| display area | 68.04(W)×120.96(H) mm |
| bezel opening | - |
| outline size | 69.44(W)×126.81(H) ×0.45(D) mm |
| surface | With Polarizer |
| brightness | 0 cd/m² |
| contrast ratio | 1500:1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| display mode | FFS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 35 (Typ.)(Tr+Td) |
| glass depth | 0.15+0.15 mm |
| transmissivity | 4.69% (Typ.)(with APCF) |
| display colors | 16.7M 80% NTSC |
| lamp type | No B/L |
| frequency | - |
| touch screen | In-Cell Touch |
| driver ic | COG Built-in TD4310 |
| panel weight | TBD |
| application | Mobile Phone |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
