| Nama Wahi | NL3224BC35-22 |
| Waitohu | NLT |
| Rahi | 5.5 |
| Taupānga | IA |
| Whakatau | 320×240 |
| Te tito | LCM |
| Tirohanga | 750 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | NEC |
| panel model | NL3224BC35-22 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 5.5 inch |
| resolution | 320(RGB)×240 , QVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 111.36×83.52 mm |
| outline | 134×104.5 mm |
| surface | Clear, Hard coating (2H), Antireflection |
| brightness | 750 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit), CIE193150% |
| response time | 5/25 (Typ.)(Tr/Td) |
| viewing angle | 55/55/50/40 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 33 pins |
| input voltage | 3.3/5.0V (Typ.)(VCC) |
| application | IA |
