| Nama Wahi | AV123Z7T-A19-D8P0 |
| Waitohu | BOE |
| Rahi | 12.3 |
| Taupānga | Outdoor High Brightn |
| Whakatau | 1920×720 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1100:1 |
| Nga Tae | 16.7M |
| Whakamuri | 9S4P |
| Atanga | LVDS |
| manufacturer | BOE |
| model name | AV123Z7T-A19-D8P0 |
| screen size | 12.3 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1920(RGB)×720 167PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 292.032 × 109.512 (H×V) |
| outline(mm) | 345.19 × 149.1 × 27.93 (H×V×D) |
| bezel area(mm) | - |
| treatment | Anti Fingerprint + Antiglare, Hard coating (3H) |
| luminance | 850 cd/m² (Typ.) |
| contrast ratio | 1100 : 1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| response | 25 (Max.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | IPS, Normally Black, Transmissive |
| color depth | 16.7M 80% NTSC |
| backlight | 9S4P WLED , 50K hours , No Driver |
| mass | - |
| used for | Outdoor High Brightness Automotive Display |
| refresh rate | 60Hz |
| touchscreen | PCAP |
| signal type | LVDS (2 ch, 8-bit) , Connector 60 pins |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
