| Nama Wahi | AV080WSM-NW2 |
| Waitohu | BOE |
| Rahi | 8.0 |
| Taupānga | Automotive Display |
| Whakatau | 1024×600 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 3S10P |
| Atanga | LVDS |
| manufacturer | BOE |
| model name | AV080WSM-NW2 |
| screen size | 8.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1024(RGB)×600 (WSVGA) 148PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 176.64 × 99.36 (H×V) |
| outline(mm) | 192.8 × 116.9 × 4.7 (H×V×D) |
| bezel area(mm) | 180.1 × 103.4 (H×V) |
| treatment | - |
| luminance | 600 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | ADS, Normally Black, Transmissive |
| color depth | 262K/16.7M 50% NTSC |
| backlight | 3S10P WLED , 30K hours , No Driver |
| mass | 176/180g (Typ./Max.) |
| used for | Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 6/8-bit) , FPC 40 pins |
| voltage supply | 3.3/11.5/21/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
