| Nama Wahi | AT070TN04 |
| Waitohu | Innolux |
| Rahi | 7.0 |
| Taupānga | Automotive Display |
| Whakatau | 480×234 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 300:1 |
| Nga Tae | Full |
| Whakamuri | CCFL |
| Atanga | TFT |
| brand | Innolux |
| diagonal size | 7.0 inch |
| pixel format | 480(RGB)×234 76PPI |
| active area | 154.08(H)×86.58(V) mm |
| bezel area | - |
| luminance | 500 cd/m² (Typ.) |
| view direction | 6 o'clock |
| viewing angle | 60/60/40/60 (Typ.)(CR≥10) |
| support color | Full color |
| weight | 160g (Typ.) |
| frame rate | 60Hz |
| interface type | TFT Specific Analog RGB , 26 pins FPC |
| power supply | 5.0/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| model | AT070TN04 |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 164.9(H)×100(V) ×6(D) mm |
| treatment | Antiglare |
| contrast ratio | 300:1 (Typ.) (TM) |
| response time | 10/20 (Typ.)(Tr/Td) |
| operating mode | TN, Normally White, Transmissive |
| light source | CCFL [1 pcs] , 10K hours , W/O Driver |
| designed for | Automotive Display |
| touch panel | Without |
| AT070TN01 | Innolux | 7.0 | 480×234 |
| AT070TN07 V.A | Innolux | 7.0 | 480×234 |
| AT070TN07 V.D | Innolux | 7.0 | 480×234 |
| AT070TN82 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN83 | Innolux | 7.0 | 800×480 |
| AT070TN84 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN90 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.1 TP | Innolux | 7.0 | 800×480 |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| AT070TNA2 | Innolux | 7.0 | 1024×600 |
