| Nama Wahi | AM-800600MGTMQW-00H |
| Waitohu | AMPIRE |
| Rahi | 8.4 |
| Taupānga | Industrial |
| Whakatau | 800×600 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 600:1 |
| Nga Tae | 16.7M |
| Whakamuri | 12S4P |
| Atanga | LVDS |
| manufacturer | AMPIRE |
| model name | AM-800600MGTMQW-00H |
| screen size | 8.4 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 800(RGB)×600 (SVGA) 119PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 170.4 × 127.8 (H×V) |
| outline(mm) | 203 × 145.5 × 10.9 (H×V×D) |
| bezel area(mm) | 174.15 × 131.2 (H×V) |
| treatment | - |
| luminance | 350 cd/m² (Typ.) |
| contrast ratio | 600 : 1 (Typ.) (TM) |
| viewing angle | 75/75/60/70 (Typ.)(CR≥10) |
| response | 8 (Typ.)(Tr+Td) ms |
| good view at | - |
| work mode | TN, Normally White, Transmissive |
| color depth | 16.7M |
| backlight | 12S4P WLED , 50K hours , With LED Driver |
| mass | TBD |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 8-bit) , Connector 20 pins |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
