| Nama Wahi | G084SN05 V3 |
| Waitohu | AUO |
| Rahi | 8.4 |
| Taupānga | IA |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | G084SN05 V3 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.4 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 170.4×127.8 mm |
| outline | 203×142.5×8.3 mm |
| surface | |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 10/25 (Typ.)(Tr/Td) |
| viewing angle | 60/60/60/40 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
| G084SN02 V0 | AUO | 8.4 | 800×600 |
| G084SN03 V0 | AUO | 8.4 | 800×600 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| G084SN03 V2 | AUO | 8.4 | 800×600 |
| G084SN03 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V5 | AUO | 8.4 | 800×600 |
| G084SN05 V7 | AUO | 8.4 | 800×600 |
| G084SN05 V8 | AUO | 8.4 | 800×600 |
| G084SN05 V9 | AUO | 8.4 | 800×600 |
| CLAA057VA01CW | CPT | 5.7 | 640×480 |
| EL160.80.50 IN | Lumineq | 3.5 | 160×80 |
| KCS072VG1MB-G42 | Kyocera | 7.2 | 640×480 |
| LQ121S1DG41 | SHARP | 12.1 | 800×600 |
| LQ64D343R | SHARP | 6.4 | 640×480 |
| LQ9D01C | SHARP | 8.4 | 640×480 |
| RGS10096064YR000 | RiTdisplay | 0.95 | 96×64 |
| RGS32256064WH002 | RiTdisplay | 3.2 | 256×64 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
| UG-5664ASWEF01 | WiseChip | 3.1 | 256×64 |
