| Nama Wahi | G084SN05 V5 |
| Waitohu | AUO |
| Rahi | 8.4 |
| Taupānga | IA |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | Analog + Digital |
| panel brand | AUO |
| panel model | G084SN05 V5 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.4 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 170.4×127.8 mm |
| outline | 203×142.5×12.7 mm |
| surface | |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 10/25 (Typ.)(Tr/Td) |
| viewing angle | 60/60/60/40 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | Analog RGB + TTL (1 ch, 6-bit), 45 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
| G084SN02 V0 | AUO | 8.4 | 800×600 |
| G084SN03 V0 | AUO | 8.4 | 800×600 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| G084SN03 V2 | AUO | 8.4 | 800×600 |
| G084SN03 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V5 | AUO | 8.4 | 800×600 |
| G084SN05 V7 | AUO | 8.4 | 800×600 |
| G084SN05 V8 | AUO | 8.4 | 800×600 |
| G084SN05 V9 | AUO | 8.4 | 800×600 |
| AM-320240N1TMQW-T30H-D(R) | AMPIRE | 5.7 | 320×240 |
| EL240.128.45 CC | Lumineq | 4.8 | 240×128 |
| KL6448USTS-FFW | Kyocera | 6.9 | 640×480 |
| KS3224ASTT-FW-X20 | Kyocera | 5.7 | 320×240 |
| LB121S03-TL03 | LG Display | 12.1 | 800×600 |
| LQ121S1LG79 | SHARP | 12.1 | 800×600 |
| NL8060BC21-11C | NLT | 8.4 | 800×600 |
| OEL9M0065-W-E | Other | 2.7 | 256×64 |
| TFD50W72MS | TOSHIBA | 5.0 | |
| UG-2832TLBGG01 | WiseChip | 1.0 | 128×32 |
