| Nama Wahi | AM-800480R2TMQW-U0H |
| Waitohu | AMPIRE |
| Rahi | 7.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 250:1 |
| Nga Tae | 65K |
| Whakamuri | WLED |
| Atanga | UART |
| manufacturer | AMPIRE |
| model name | AM-800480R2TMQW-U0H |
| screen size | 7.0 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 133PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 152.4 × 91.44 (H×V) |
| outline(mm) | 178.5 × 110 × 20.4 (H×V×D) |
| bezel area(mm) | 155.3 × 94.3 (H×V) |
| treatment | - |
| luminance | 400 cd/m² (Typ.) |
| contrast ratio | 250 : 1 (Typ.) (TM) |
| viewing angle | 70/70/60/60 (Typ.)(CR≥10) |
| response | 50 (Typ.)(Tr+Td) ms |
| good view at | - |
| work mode | TN, Normally White, Transmissive |
| color depth | 65K 48% NTSC |
| backlight | WLED , With LED Driver |
| mass | - |
| used for | Industrial |
| refresh rate | - |
| touchscreen | Without |
| signal type | UART , 8 pins Connector |
| voltage supply | 4.6/26.0V (Min./Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AM-800480-050D | Other | 5.0 | 800×480 |
| AM-800480LATMQW-TN0H | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-00H-F | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| AM-800480R3TMQW-B2H | AMPIRE | 7.0 | 800×480 |
| AM-800480RCTMQW-00H | AMPIRE | 7.0 | 800×480 |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-W0 | AMPIRE | 7.0 | 800×480 |
