| Nama Wahi | AM-800480LTMQW-00H-F |
| Waitohu | AMPIRE |
| Rahi | 5.0 |
| Taupānga | IA |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 250:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | AMPIRE |
| panel model | AM-800480LTMQW-00H-F |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 5.0 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 108×64.8 mm |
| outline | 119×77.1×3.41 mm |
| surface | Glare (Haze 0%) |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 250:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193152% |
| response time | 15/35 (Typ.)(Tr/Td) |
| viewing angle | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S6PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 45 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
