| Nama Wahi | AM-800480D1TMQW-00H |
| Waitohu | AMPIRE |
| Rahi | 8.0 |
| Taupānga | Industrial Automotiv |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | |
| brand | AMPIRE |
| model | AM-800480D1TMQW-00H |
| diagonal size | 8.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800(RGB)×480 [WVGA] 116PPI |
| configuration | RGB Vertical Stripe |
| active area | 176.64(H)×99.36(V) mm |
| outline dim. | 192.8(H)×116.9(V) ×6.7(D) mm |
| bezel area | 180.1(H)×103.4(V) mm |
| treatment | Antiglare |
| luminance | 450 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| view direction | - |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 262K/16.7M |
| light source | WLED , 20K hours , W/O Driver |
| weight | 251g (Typ.) |
| designed for | Industrial Automotive Display |
| frame rate | 60Hz |
| touch panel | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
