| Nama Wahi | AM-800480CTZQW-A5H |
| Waitohu | AMPIRE |
| Rahi | 7.0 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 800×480 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 262K |
| Whakamuri | 6S5P |
| Atanga | LVDS |
| manufacturer | AMPIRE |
| model name | AM-800480CTZQW-A5H |
| screen size | 7.0 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 133PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 152.4 × 91.44 (H×V) |
| outline(mm) | 165 × 104.4 × 11.61 (H×V×D) |
| bezel area(mm) | 15.48 × 93.85 (H×V) |
| treatment | - |
| luminance | 1500 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | IPS, Normally Black, Transmissive |
| color depth | 262K 58% NTSC |
| backlight | 6S5P WLED , 50K hours , With LED Driver |
| mass | - |
| used for | Industrial Outdoor High Brightness |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 6-bit) , 20 pins Connector |
| voltage supply | 12.0V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
