| Nama Wahi | AM-800480AZTMQW-50H |
| Waitohu | AMPIRE |
| Rahi | 5.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 600:1 |
| Nga Tae | 16.7M |
| Whakamuri | 3S6P |
| Atanga | |
| panel brand | AMPIRE |
| panel size | 5.0" |
| resolution | 800(RGB)×480, WVGA, 188PPI |
| display area | 108(W)×64.8(H) mm |
| outline size | 119.7(W)×78(H) ×6.1(D) mm |
| brightness | 1000 cd/m² (Typ.) |
| viewing angle | 75/75/70/60 (Typ.)(CR≥10) |
| best view on | - |
| display colors | 16.7M 47% NTSC |
| frequency | 60Hz |
| weight | - |
| panel model | AM-800480AZTMQW-50H |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Antiglare |
| contrast ratio | 600:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 2/6 (Typ.)(Tr/Td) |
| lamp type | 3S6P WLED , 50K hours , Without Driver |
| touch screen | Without |
| application | Industrial |
