| Nama Wahi | AM-800480AZTMQW-05H |
| Waitohu | AMPIRE |
| Rahi | 5.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 600:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | |
| brand | AMPIRE |
| model | AM-800480AZTMQW-05H |
| diagonal size | 5.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800(RGB)×480 [WVGA] 188PPI |
| configuration | RGB Vertical Stripe |
| active area | 108(H)×64.8(V) mm |
| outline dim. | 118.5(H)×77.1(V) ×7.41(D) mm |
| bezel area | 110.6(H)×67.4(V) mm |
| treatment | - |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) (TM) |
| view direction | - |
| response time | 2/6 (Typ.)(Tr/Td) |
| viewing angle | 75/75/70/60 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 262K 47% NTSC |
| light source | WLED [3S7P] , 30K hours , With LED Driver |
| weight | - |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
