| Nama Wahi | AM-640480VTZQW-00H |
| Waitohu | AMPIRE |
| Rahi | 5.7 |
| Taupānga | Industrial |
| Whakatau | 640×480 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1200:1 |
| Nga Tae | 262K |
| Whakamuri | 4S7P |
| Atanga | CMOS |
| panel brand | AMPIRE |
| panel size | 5.7" |
| resolution | 640(RGB)×480, VGA, 141PPI |
| display area | 115.2(W)×86.4(H) mm |
| outline size | 127(W)×98.43(H) ×6.9(D) mm |
| brightness | 500 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 262K 63% NTSC |
| frequency | 60Hz |
| panel weight | - |
| signal interface | CMOS (1 ch, 6-bit) , 40 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel model | AM-640480VTZQW-00H |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 118.0(W)×89.2(H) mm |
| surface | - |
| contrast ratio | 1200:1 (Typ.) (TM) |
| display mode | IPS, Normally Black, Transmissive |
| response time | 30 (Typ.)(Tr+Td) |
| lamp type | 4S7P WLED , 50K hours , With LED Driver |
| touch screen | Without |
| application | Industrial |
