| Nama Wahi | LQ057AC111 |
| Waitohu | Other |
| Rahi | 5.7 |
| Taupānga | IA |
| Whakatau | 320×240 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 200:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | Parallel/Serial |
| panel brand | CHILIN |
| panel model | LQ057AC111 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 5.7 inch |
| resolution | 320(RGB)×240 , QVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 115.2×86.4 mm |
| outline | 126×101.55 mm |
| surface | Antiglare |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 200:1 (Typ.) |
| display colors | 16.7M |
| response time | 15/35 (Typ.)(Tr/Td) |
| viewing angle | 65/65/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S7PWLEDWithout Driver |
| signal interface | Digital RGB (8/24-bit), CCIR601/656, 50 pins |
| input voltage | 3.3/5.0V (Typ.)(VDD/AVDD) |
| application | IA |
