| Nama Wahi | TX16D18VM2CAB |
| Waitohu | KOE |
| Rahi | 6.2 |
| Taupānga | IA |
| Whakatau | 800×300 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 200:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | HITACHI |
| panel model | TX16D18VM2CAB |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 6.2 inch |
| resolution | 800(RGB)×300 , HSVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 148.8×53.76 mm |
| outline | 173×70 mm |
| surface | |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 200:1 (Typ.) |
| display colors | 262K (6-bit), CIE193160% |
| response time | 45 (Typ.)(Tr+Td) |
| viewing angle | 70/70/50/80 (Typ.)(CR≥5)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S7PWLEDWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 40 pins |
| input voltage | 3.3V (Typ.)(VDD) |
| application | IA |
