| Nama Wahi | AM-1024600L2HMQW-T01H |
| Waitohu | AMPIRE |
| Rahi | 10.1 |
| Taupānga | Industrial |
| Whakatau | 1024×600 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AMPIRE |
| model | AM-1024600L2HMQW-T01H |
| diagonal size | 10.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×600 [WSVGA] 117PPI |
| configuration | RGB Vertical Stripe |
| active area | 222.72(H)×125.28(V) mm |
| outline dim. | 235(H)×145.8(V) ×9.8(D) mm |
| bezel area | 225.92(H)×128.48(V) mm |
| treatment | - |
| luminance | 800 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| view direction | - |
| response time | 4/12 (Typ.)(Tr/Td) |
| viewing angle | 70/70/70/50 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 262K 47% NTSC |
| light source | WLED [6S6P] , 50K hours , With LED Driver |
| weight | TBD |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | 4-wire Resistive Touch |
| interface type | LVDS (1 ch, 6-bit) , 30 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -5 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
