| Nama Wahi | AM-1024600K5TMQW-01H |
| Waitohu | AMPIRE |
| Rahi | 7.0 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1024×600 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 700:1 |
| Nga Tae | 16.7M |
| Whakamuri | 8S3P |
| Atanga | LVDS |
| manufacturer | AMPIRE |
| screen size | 7.0 inch |
| pixel number | 1024(RGB)×600 (WSVGA) 169PPI |
| active area(mm) | 153.6 × 90 (H×V) |
| bezel area(mm) | 156.2 × 92.6 (H×V) |
| luminance | 1000 cd/m² (Typ.) |
| viewing angle | 75/75/70/75 (Typ.)(CR≥10) |
| good view at | - |
| color depth | 16.7M |
| mass | TBD |
| refresh rate | 60Hz |
| signal type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| model name | AM-1024600K5TMQW-01H |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 165.5 × 104.44 × 9.46 (H×V×D) |
| treatment | Glare (Haze 0%), Hard coating |
| contrast ratio | 700 : 1 (Typ.) (TM) |
| response | 20/20 (Typ.)(Tr/Td) ms |
| work mode | TN, Normally White, Transmissive |
| backlight | 8S3P WLED , 50K hours , With LED Driver |
| used for | Industrial Outdoor High Brightness |
| touchscreen | Without |
