| Nama Wahi | AM-1024600DTZQW-TA6H |
| Waitohu | AMPIRE |
| Rahi | 7.0 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1024×600 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AMPIRE |
| model | AM-1024600DTZQW-TA6H |
| diagonal size | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×600 [WSVGA] 170PPI |
| configuration | RGB Vertical Stripe |
| active area | 154.221(H)×85.92(V) mm |
| outline dim. | 164.9(H)×128(V) ×12.6(D) mm |
| luminance | 850 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 13/15 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | IPS, Normally Black, Transmissive |
| support color | 16.7M 58% NTSC |
| light source | WLED , 50K hours , With LED Driver |
| weight | - |
| designed for | Industrial Outdoor High Brightness |
| frame rate | 60Hz |
| touch panel | PCAP |
| interface type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
