| Nama Wahi | AM-1024600DTZQW-A6H |
| Waitohu | AMPIRE |
| Rahi | 7.0 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1024×600 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | AMPIRE |
| model name | AM-1024600DTZQW-A6H |
| screen size | 7.0 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1024(RGB)×600 (WSVGA) 170PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 154.221 × 85.92 (H×V) |
| outline(mm) | 164.9 × 100 (H×V×D) |
| bezel area(mm) | 158 × 89.7 (H×V) |
| treatment | Antiglare |
| luminance | 1000 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 13/15 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | IPS, Normally Black, Transmissive |
| color depth | 16.7M |
| backlight | WLED , 50K hours , With LED Driver |
| mass | - |
| used for | Industrial Outdoor High Brightness |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
