Nama Wahi | WEO012864DB |
Waitohu | Winstar |
Rahi | 0.96 |
Taupānga | Handheld & PDA H |
Whakatau | 128×64 |
Te tito | PM-OLED, OLED |
Tirohanga | |
CR | |
Nga Tae | Mono(Blue) |
Whakamuri | self |
Atanga | |
brand | Winstar |
model | WEO012864DB |
diagonal size | 0.96 inch |
type | PM-OLED, OLED |
pixel format | 128×64 149PPI |
configuration | Rectangle |
active area | 21.738(H)×10.858(V) mm |
outline dim. | 26.7(H)×19.26(V) ×1.81(D) mm |
bezel area | 23.938(H)×12.058(V) mm |
treatment | - |
view direction | Symmetry |
response time | - |
viewing angle | - |
operating mode | - |
support color | Mono(Blue) |
light source | self |
weight | - |
designed for | Handheld & PDA Healthcare Instruments & Meters |
frame rate | - |
touch panel | Without |
3.0V (Typ.) |
