| Nama Wahi | TX20D208VM0BAA |
| Waitohu | HITACHI |
| Rahi | 8.0 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | HITACHI |
| panel model | TX20D208VM0BAA |
| panel size | 8.0" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 800(RGB)×480, WVGA, 116PPI |
| pixel format | RGB Vertical Stripe |
| display area | 174(W)×104.4(H) mm |
| bezel opening | 177.4(W)×107.8(H) mm |
| outline size | 190.8(W)×120.5(H) ×16.2(D) mm |
| surface | - |
| brightness | 1200 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| display mode | IPS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 30 (Max.)(Tr+Td) |
| display colors | 16.7M 70% NTSC |
| lamp type | WLED , 100K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 275g (Typ.) |
| application | Industrial Outdoor High Brightness Automotive Display |
| signal interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C |
