| Nama Wahi | TV101WUM-NM1 |
| Waitohu | BOE |
| Rahi | 10.1 |
| Taupānga | Pad & Tablet |
| Whakatau | 1200×1920 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | 8S4P |
| Atanga | MIPI |
| manufacturer | BOE |
| model name | TV101WUM-NM1 |
| screen size | 10.1 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1200(RGB)×1920 (WUXGA) 225PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 135.36 × 216.576 (H×V) |
| outline(mm) | 143 × 227.926 × 4.4 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare, Hard coating, Antireflection |
| luminance | - |
| contrast ratio | 900 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 30 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | ADS, Normally Black, Transmissive |
| color depth | 16.7M |
| backlight | 8S4P WLED , 30K hours , No Driver |
| mass | 145g (Max.) |
| used for | Pad & Tablet |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | MIPI (4 data lanes) Connector |
| voltage supply | 3.3V (Typ.)(VDD) |
| max. ratings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
