| Nama Wahi | TM123XDHP01 |
| Waitohu | TIANMA |
| Rahi | 12.3 |
| Taupānga | Industrial Automotiv |
| Whakatau | 1920×720 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | |
| brand | TIANMA |
| diagonal size | 12.3 inch |
| pixel format | 1920(RGB)×720 166PPI |
| active area | 292.32(H)×109.62(V) mm |
| luminance | - |
| view direction | Symmetry |
| viewing angle | - |
| support color | 16.7M sRGB |
| weight | - |
| frame rate | 60Hz |
| environment | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
| model | TM123XDHP01 |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | - |
| contrast ratio | 1000:1 (Typ.) (TM) |
| response time | 25 (Typ.)(Tr+Td) |
| operating mode | SFT, Normally Black, Transmissive |
| light source | WLED |
| designed for | Industrial Automotive Display |
| touch panel | Without |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
