| Nama Wahi | TM070RDHP10-00 |
| Waitohu | TIANMA |
| Rahi | 7.0 |
| Taupānga | Automotive Display |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | Parallel |
| brand | TIANMA |
| model | TM070RDHP10-00 |
| diagonal size | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800(RGB)×480 [WVGA] 133PPI |
| configuration | RGB Vertical Stripe |
| active area | 152.4(H)×91.44(V) mm |
| outline dim. | 165.1(H)×108.44(V) ×13(D) mm |
| bezel area | 155.4(H)×94.44(V) mm |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 1000 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 35 (Max.)(Tr+Td) |
| viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
| operating mode | SFT, Normally Black, Transmissive |
| support color | 16.7M 71% NTSC |
| light source | WLED [8S2P] , 10K hours , W/O Driver |
| weight | 180g (Max.) |
| designed for | Automotive Display |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | Parallel RGB (1 ch, 6/8-bit) , 40 pins FPC |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -45 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
