| Nama Wahi | TM062RDH03 |
| Waitohu | Tianma |
| Rahi | 6.2 |
| Taupānga | CNS |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 500:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | TIANMA |
| panel model | TM062RDH03 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 6.2 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 137.4×77.28 mm |
| outline | 155.2×88.2×5.2 mm |
| surface | Antiglare |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193147% |
| response time | 20 (Typ.)(Tr+Td) |
| viewing angle | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 3S8PWLEDWithout Driver |
| signal interface | TTL (1 ch, 8-bit), 60 pins |
| input voltage | 3.3/9.84/19/-7V (Typ.)(AVCC/DVCC/VGH/VGL) |
| application | CNS |
