| Nama Wahi | HT07W12-200 |
| Waitohu | HYDIS |
| Rahi | 7.0 |
| Taupānga | CNS |
| Whakatau | 480×234 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 250:1 |
| Nga Tae | Full color |
| Whakamuri | CCFL |
| Atanga | Analog |
| panel brand | BOE HYDIS |
| panel model | HT07W12-200 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 480(RGB)×234 |
| display mode | TN, Normally White, Transmissive |
| active area | 154.08×87.05 mm |
| outline | 167×102×12.5 mm |
| surface | Antiglare, Hard coating |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 250:1 (Typ.) |
| display colors | Full color |
| response time | 10/25 (Typ.)(Tr/Td) |
| viewing angle | 60/60/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | Analog RGB + Composite Video (NTSC/PAL), 30 pins |
| input voltage | 9.0/5.0/18/-15/-10V (Typ.)(VCOM/VDD/VGH/VGL/VDL) |
| application | CNS |
