| Nama Wahi | TM035HDZP04 |
| Waitohu | TIANMA |
| Rahi | 3.5 |
| Taupānga | Automotive Display |
| Whakatau | 240×320 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | |
| panel brand | TIANMA |
| panel size | 3.5" |
| resolution | 240(RGB)×320, QVGA, 114PPI |
| display area | 53.28(W)×71.04(H) mm |
| brightness | - |
| viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 262K |
| frequency | 60Hz |
| weight | - |
| panel model | TM035HDZP04 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 58.28(W)×74.04(H) mm |
| contrast ratio | 1000:1 (Typ.) (TM) |
| display mode | SFT, Normally Black, Transmissive |
| response time | 30 (Typ.)(Tr+Td) |
| lamp type | WLED , 10K hours , Without Driver |
| touch screen | - |
| application | Automotive Display |
