TM035KDH16-09

TM035KDH16-09
TM035KDH16-09
TM035KDH16-09 thumb TM035KDH16-09 thumb
Waitohu
Tianma
Rahi
3.5
Taupānga
DSC
Whakatau
320×240
Te tito
LCM
Tirohanga
330
CR
500:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
Parallel/Serial
In Stock
1708
Whakatakotoranga

Nama Wahi TM035KDH16-09
WaitohuTianma
Rahi3.5
TaupāngaDSC
Whakatau320×240
Te titoLCM
Tirohanga330
CR500:1
Nga Tae16.7M
WhakamuriWLED
AtangaParallel/Serial
panel brandTIANMA
panel modelTM035KDH16-09
panel type a-Si TFT-LCD , LCM
panel size3.5 inch
resolution320(RGB)×240 , QVGA
display modeTN, Normally White, Transmissive
active area70.08×52.56 mm
outline76.9×63.9×3.35 mm
surfaceAntiglare
brightness330 cd/m² (Typ.)
contrast ratio500:1 (Typ.)
display colors16.7M (8-bit), CIE193150%
response time20 (Typ.)(Tr+Td)
viewing angle70/70/60/70 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type6S1PWLEDWithout Driver
signal interfaceDigital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins
input voltage3.3V (Typ.)
applicationDSC
