AUO A027DTN01.2 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


A027DTN01.2

A027DTN01.2
A027DTN01.2 thumb
Waitohu
AUO
Rahi
2.7
Taupānga
DSC
Whakatau
320×240
Te tito
LCM
Tirohanga
400
CR
400:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
Serial RGB
In Stock
6637
Whakatakotoranga

Nama Wahi A027DTN01.2
WaitohuAUO
Rahi2.7
TaupāngaDSC
Whakatau320×240
Te titoLCM
Tirohanga400
CR400:1
Nga Tae16.7M
WhakamuriWLED
AtangaSerial RGB
panel brandAUO
panel modelA027DTN01.2
panel type LTPS TFT-LCD , LCM
panel size2.7 inch
resolution320(RGB)×240 , QVGA
display modeTN, Normally White, Transmissive
active area54×40.5 mm
outline63.5×46.6×2.6 mm
surfaceHard coating
brightness400 cd/m² (Typ.)
contrast ratio400:1 (Typ.)
display colors16.7M (8-bit)
response time10/25 (Typ.)(Tr/Td)
viewing angle60/60/50/60 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type2S1PWLEDWithout Driver
signal interfaceSerial RGB (8-bit) + SPI, CCIR601/656, 39 pins
input voltage3.3V (Typ.)
applicationDSC
Tauira Whanau
A027DN01 V1 AUO 2.7 320×240
A027DN01 VQ AUO 2.7 320×240
A027DN01 VR AUO 2.7 320×240
A027DN03 V1 AUO 2.7 320×240
A027DN03 V2 AUO 2.7 320×240
A027DN03 V4 AUO 2.7 320×240
A027DN03 V5 AUO 2.7 320×240
A027DN03 V8 AUO 2.7 320×240
A027DN04 V3 AUO 2.7 320×240
A027DN04 V7 AUO 2.7 320×240
Hua wera
990000270 TPO 2.5 320×240
A017CN01 V2 AUO 1.7 480×240
A020BL01 V0 AUO 2.0 640×240
A025DN01 V9 AUO 2.5 320×240
A027DN03 V5 AUO 2.7 320×240
LS020A8DX02 SHARP 2.0 320×240
TM027CDH02 Tianma 2.7 320×240
TM035KDH03-79 Tianma 3.5 320×240
TM035KDH05 Tianma 3.5 320×240
TM035KDH16-09 Tianma 3.5 320×240
