AUO T320XVN01.0 CELL Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


T320XVN01.0 CELL

T320XVN01.0 CELL
T320XVN01.0 CELL
T320XVN01.0 CELL
T320XVN01.0 CELL thumb T320XVN01.0 CELL thumb T320XVN01.0 CELL thumb
Waitohu
AUO
Rahi
31.5
Taupānga
LCTV
Whakatau
1366×768
Te tito
CELL
Tirohanga
0
CR
3000:1
Nga Tae
16.7M
Whakamuri
No B/L
Atanga
LVDS
In Stock
9
Whakatakotoranga

Nama Wahi T320XVN01.0 CELL
WaitohuAUO
Rahi31.5
TaupāngaLCTV
Whakatau1366×768
Te titoCELL
Tirohanga0
CR3000:1
Nga Tae16.7M
WhakamuriNo B/L
AtangaLVDS
panel brandAUO
panel modelT320XVN01.0 CELL
panel type a-Si TFT-LCD , CELL
panel size31.5 inch
resolution1366×768(RGB) , WXGA
display modeAMVA, Normally Black, Transmissive
active area697.685×392.256 mm
outline716.1×408.7 mm
surfaceAntiglare (Haze 2%), Hard coating (3H)
glass depth0.50+0.50 mm
transmissivity6.1% (Typ.)(with Polarizer)
contrast ratio3000:1 (Typ.)
display colors16.7M (8-bit), CIE193178%
response time6.5 (Typ.)(G to G)
viewing angle89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
signal interfaceLVDS (1 ch, 8-bit), 30 pins
input voltage12.0V (Typ.)
applicationLCTV
Tauira Whanau
LC320W01-SL01 LG Display 31.5 1366×768
MT3151A05-2 CSOT 31.5 1366×768
T320XVN01.0 AUO 31.5 1366×768
T320XVN01.0 CELL AUO 31.5 1366×768
T320XVN02.0 AUO 31.5 1366×768
T320XVN02.0 CELL AUO 31.5 1366×768
T320XVN02.9 CELL AUO 31.5 1366×768
T320XVN02.A CELL AUO 31.5 1366×768
T320XVN05.0 AUO 31.5 1366×768
V315B5-L01 Innolux 31.5 1366×768
