T315HW07 V2

T315HW07 V2
T315HW07 V2
T315HW07 V2 thumb T315HW07 V2 thumb
Waitohu
AUO
Rahi
31.5
Taupānga
LCTV
Whakatau
1920×1080
Te tito
LCM
Tirohanga
400
CR
4000:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
LVDS
In Stock
8
Whakatakotoranga

Nama Wahi T315HW07 V2
WaitohuAUO
Rahi31.5
TaupāngaLCTV
Whakatau1920×1080
Te titoLCM
Tirohanga400
CR4000:1
Nga Tae16.7M
WhakamuriWLED
AtangaLVDS
panel brandAUO
panel modelT315HW07 V2
panel type a-Si TFT-LCD , LCM
panel size31.5 inch
resolution1920(RGB)×1080 , FHD
display modeAMVA3, Normally Black, Transmissive
active area698.4×392.85 mm
outline741.4×435.8 mm
surfaceAntiglare, Hard coating (3H)
brightness400 cd/m² (Typ.)
contrast ratio4000:1 (Typ.)
display colors16.7M (8-bit), CIE193172%
response time6.5 (Typ.)(G to G)
viewing angle89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp typeWLEDEmbedded (LED Driver)
signal interfaceLVDS (2 ch, 8-bit), 51 pins
input voltage12.0V (Typ.)
applicationLCTV
