AUO T315HW04 VC Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


T315HW04 VC

T315HW04 VC
T315HW04 VC
T315HW04 VC
T315HW04 VC thumb T315HW04 VC thumb T315HW04 VC thumb
Waitohu
AUO
Rahi
31.5
Taupānga
LCTV
Whakatau
1920×1080
Te tito
LCM
Tirohanga
450
CR
5000:1
Nga Tae
16.7M
Whakamuri
CCFL
Atanga
LVDS
In Stock
2570
Whakatakotoranga

Nama Wahi T315HW04 VC
WaitohuAUO
Rahi31.5
TaupāngaLCTV
Whakatau1920×1080
Te titoLCM
Tirohanga450
CR5000:1
Nga Tae16.7M
WhakamuriCCFL
AtangaLVDS
panel brandAUO
panel modelT315HW04 VC
panel type a-Si TFT-LCD , LCM
panel size31.5 inch
resolution1920(RGB)×1080 , FHD
display modeAMVA3, Normally Black, Transmissive
active area698.4×392.85 mm
outline760×450×47.9 mm
surfaceAntiglare (Haze 2%), Hard coating (3H)
brightness450 cd/m² (Typ.)
contrast ratio5000:1 (Typ.)
display colors16.7M (8-bit), CIE193172%
response time6.5 (Typ.)(G to G)
viewing angle89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type4 pcsCCFLEmbedded (Inverter)
signal interfaceLVDS (2 ch, 8-bit), 51 pins
input voltage12.0V (Typ.)
applicationLCTV
