V420H2-LS2 Rev.C7

V420H2-LS2 Rev.C7
V420H2-LS2 Rev.C7
V420H2-LS2 Rev.C7
V420H2-LS2 Rev.C7 thumb V420H2-LS2 Rev.C7 thumb V420H2-LS2 Rev.C7 thumb
Waitohu
Innolux
Rahi
42
Taupānga
LCTV
Whakatau
1920×1080
Te tito
LCM
Tirohanga
370
CR
5000:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
LVDS
In Stock
15342
Whakatakotoranga

Nama Wahi V420H2-LS2 Rev.C7
WaitohuInnolux
Rahi42
TaupāngaLCTV
Whakatau1920×1080
Te titoLCM
Tirohanga370
CR5000:1
Nga Tae16.7M
WhakamuriWLED
AtangaLVDS
panel brandCHIMEI INNOLUX
panel modelV420H2-LS2 Rev.C7
panel type a-Si TFT-LCD , LCM
panel size42 inch
resolution1920(RGB)×1080 , FHD
display modeSuper MVA, Normally Black, Transmissive
active area930.24×523.26 mm
outline968.4×564×27.7 mm
surfaceAntiglare (Haze 11%), Hard coating (3H)
brightness370 cd/m² (Typ.)
contrast ratio5000:1 (Typ.)
display colors16.7M (8-bit), CIE193172%
response time6 (Typ.)(G to G)
viewing angle88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frequency120Hz (60Hz Input)
lamp typeWLEDEmbedded (LED Driver)
signal interfaceLVDS (2 ch, 8-bit), 61 pins
input voltage12.0V (Typ.)
applicationLCTV
