Nama Wahi | LC840EQD-SEM1 |
Waitohu | LG Display |
Rahi | 84 |
Taupānga | LCTV |
Whakatau | 3840×2160 |
Te tito | LCM |
Tirohanga | 350 |
CR | 1400:1 |
Nga Tae | 16.7M/1.06B |
Whakamuri | WLED |
Atanga | V-by-One |
panel brand | LG Display |
panel model | LC840EQD-SEM1 |
panel type | a-Si TFT-LCD , LCM |
panel size | 84 inch |
resolution | 3840(RGB)×2160 , UHD |
display mode | S-IPS, Normally Black, Transmissive |
active area | 1860.48×1046.52 mm |
outline | 1904×1096×42.3 mm |
surface | Antiglare (Haze 10%), Hard coating (3H) |
brightness | 350 cd/m² (Typ.) |
contrast ratio | 1400:1 (Typ.) |
display colors | 16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172% |
response time | 5 (Typ.)(G to G), 8 (Typ.)(MPRT) |
viewing angle | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
frequency | 120Hz+120Hz |
lamp type | WLEDEmbedded (LED Driver) |
signal interface | V-by-One 16 lane, 97 pins |
input voltage | 12.0V (Typ.) |
application | LCTV |
