| Nama Wahi | T315XW02 VD |
| Waitohu | AUO |
| Rahi | 31.5 |
| Taupānga | LCTV |
| Whakatau | 1366×768 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 1500:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | T315XW02 VD |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 31.5 inch |
| resolution | 1366(RGB)×768 , WXGA |
| display mode | AMVA, Normally Black, Transmissive |
| active area | 697.685×392.256 mm |
| outline | 760×450 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 1500:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | 6.5 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | CCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 12.0V (Typ.) |
| application | LCTV |
| T315XW01 V5 | AUO | 31.5 | 1366×768 |
| T315XW02 V3 | AUO | 31.5 | 1366×768 |
| T315XW02 VC | AUO | 31.5 | 1366×768 |
| T315XW02 VD | AUO | 31.5 | 1366×768 |
| T315XW02 VT | AUO | 31.5 | 1366×768 |
| T315XW03 V3 | AUO | 31.5 | 1366×768 |
| T315XW03 V4 | AUO | 31.5 | 1366×768 |
| T315XW04 V0 | AUO | 31.5 | 1366×768 |
| T315XW04 V1 | AUO | 31.5 | 1366×768 |
| T315XW04 V3 | AUO | 31.5 | 1366×768 |
| LC150X01-SL01 | LG Display | 15.0 | 1024×768 |
| LC215EUE-SDP1 | LG Display | 21.5 | 1920×1080 |
| LC420DUE-SFU2 | LG Display | 42 | 1920×1080 |
| LC420EUN-SFF2 | LG Display | 42 | 1920×1080 |
| LC470EUE-SEM1 | LG Display | 47 | 1920×1080 |
| LC550DUH-PGF2 | LG Display | 55 | 1920×1080 |
| T315XW02 VF | AUO | 31.5 | 1366×768 |
| T315XW03 VD | AUO | 31.5 | 1366×768 |
| T315XW03 VE | AUO | 31.5 | 1366×768 |
| T320XVN01.0 CELL | AUO | 31.5 | 1366×768 |
