| Nama Wahi | SVA170SX01TB |
| Waitohu | SVA-NEC |
| Rahi | 17.0 |
| Taupānga | DMPC |
| Whakatau | 1280×1024 |
| Te tito | LCM |
| Tirohanga | 300 |
| CR | 600:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | SVA-NEC |
| panel model | SVA170SX01TB 1 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1280(RGB)×1024 , SXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 337.92×270.336 mm |
| outline | 358.5×296.5×17.5 mm |
| surface | |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193172% |
| response time | 2/6 (Typ.)(Tr/Td) |
| viewing angle | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
| G170ETN02.0 | AUO | 17.0 | 1280×1024 |
| LC170WXN-SAA1 | LG Display | 17.0 | 1366×768 |
| LM170E01-TLBF | LG Display | 17.0 | 1280×1024 |
| LQ170K1LW02 | SHARP | 17.0 | 1280×768 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTN170U1-L02 | Samsung | 17.0 | 1920×1200 |
| M170EG01 VA | AUO | 17.0 | 1280×1024 |
| M170EG01 VG | AUO | 17.0 | 1280×1024 |
| MT170EN01 V.9 | Innolux | 17.0 | 1280×1024 |
| SVA170SX01TB | SVA-NEC | 17.0 | 1280×1024 |
| LC215DT4A | PANDA | 21.5 | 1920×1080 |
| LM220W1-A2MN | LG Display | 22.0 | 1600×1024 |
| LM230WF3-SLL1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SSA1 | LG Display | 23.0 | 1920×1080 |
| LM270WQ1-SDDA | LG Display | 27.0 | 2560×1440 |
| LTM170E8-L21 | Samsung | 17.0 | 1280×1024 |
| LTM184HL01 | Samsung | 18.4 | 1920×1080 |
| M170EN01 V9 | AUO | 17.0 | 1280×1024 |
| MV236WHM-N10 | BOE | 23.6 | 1366×768 |
| TMS150XG1-10TB Rev.E | Tianma | 15.0 | 1024×768 |
