| Nama Wahi | P101DEA-AZ0 |
| Waitohu | Innolux |
| Rahi | 10.1 |
| Taupānga | Pad & Tablet |
| Whakatau | 800×1280 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 4 |
| Atanga | MIPI |
| manufacturer | Innolux |
| model name | P101DEA-AZ0 |
| screen size | 10.1 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 800(RGB)×1280 (WXGA) 150PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 135.36 × 216.576 (H×V) |
| outline(mm) | 143.24 × 229.18 × 4.4 (H×V×D) |
| bezel area(mm) | - |
| treatment | Glare (Haze 0%), Hard coating |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Min.)(CR≥10) |
| response | 35 (Max.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | AAS, Normally Black, Transmissive |
| color depth | 16.7M 60% NTSC |
| backlight | 4 strings WLED , 15K hours , No Driver |
| mass | 175g (Max.) |
| used for | Pad & Tablet |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | MIPI (4 data lanes) , Connector 40 pins |
| voltage supply | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| max. ratings | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| B101AW03 V0 | AUO | 10.1 | 1024×600 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| EJ101IA-02A | Innolux | 10.1 | 1280×800 |
| HSD101PFW3-B00 | HannStar | 10.1 | 1024×600 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| LP101WH1-TLB2 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLAA | LG Display | 10.1 | 1366×768 |
| LP101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LTL101AL06-801 | Samsung | 10.1 | 1280×800 |
| N101ICG-L21 Rev.C1 | Innolux | 10.1 | 1280×800 |
