| Nama Wahi | NL192120AC25-02 |
| Waitohu | NLT |
| Rahi | 22.5 |
| Taupānga | DMPC |
| Whakatau | 1920×1200 |
| Te tito | LCM |
| Tirohanga | 420 |
| CR | 800:1 |
| Nga Tae | 1.07B |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | NEC |
| panel model | NL192120AC25-02 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 22.5 inch |
| resolution | 1920(RGB)×1200 , WUXGA |
| display mode | UA-SFT, Normally Black, Transmissive |
| active area | 483.84×302.4 mm |
| outline | 542×362 mm |
| surface | Antiglare, Hard coating (2H) |
| brightness | 420 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 1.07B (10-bit), Adobe97% |
| response time | 6/6 (Typ.)(Tr/Td) |
| viewing angle | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 120Hz |
| lamp type | 12 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (4 ch, 10-bit), 104 pins |
| input voltage | 12.0V (Typ.) |
| application | DMPC |
