NL160120BM27-07A

NL160120BM27-07A
NL160120BM27-07A thumb
Waitohu
NLT
Rahi
21.3
Taupānga
MD
Whakatau
1600×1200
Te tito
LCM
Tirohanga
CR
700:1
Nga Tae
Grayscale
Whakamuri
CCFL
Atanga
LVDS
In Stock
7352
Whakatakotoranga

Nama Wahi NL160120BM27-07A
WaitohuNLT
Rahi21.3
TaupāngaMD
Whakatau1600×1200
Te titoLCM
Tirohanga
CR700:1
Nga TaeGrayscale
WhakamuriCCFL
AtangaLVDS
panel brandNEC
panel modelNL160120BM27-07A
panel type a-Si TFT-LCD , LCM
panel size21.3 inch
resolution1600(LCR)×1200 , UXGA
display modeSA-SFT, Normally Black, Transmissive
active area432×324 mm
surfaceAntiglare, Hard coating (2H)
brightness
contrast ratio700:1 (Typ.)
display colorsGrayscale (8-bit)
response time17/18 (Typ.)(Tr/Td)
viewing angle85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp typeCCFL
signal interfaceLVDS (2 ch, 8-bit)
input voltage12.0V (Typ.)
rohs:
applicationMD
